Inputs 8 electronically balanced. [++]

Impedance (microphone) 2k ohms.

Impedance (Line) 10k ohms.

CMRR >80dB @ 1kHz.

Outputs

FOH 8 electronically balanced. [++]

MON 8 electronically balanced. [++]


Isolated Feeds 16 Transformer balanced. 2.5kVAC for 1 min.isolation.( -10dB)

Source Imp < 80ohms.

Min. Load 600ohm.

Max. Level +20dBm into 600 ohm load.

Gain 10dB, 20dB, 30dB, 40dB or 50dB via 5 position switch. Headroom meter 5 point LED @ 0, -6, -12, -18, -30dB belowclipping.


Frequency Resp ±0.5dB 20Hz - 20kHz.

Equivalent Input Noise
( 20Hz -20kHz. Unweighted)10dB


Gain: < -112dBm; 20dB Gain: < -117dBm; 30dB Gain: < -120dBm 40dB Gain: < -120dBm


Distortion < 0.01% @ 1kHz, +4dB output.


Power 80 to 250VAC @ 50/60Hz.

Consumption < 40 watts.


Weight 8.1kg. Net (9.5kg. Shipping)

Size 3.5"(2U) x 19" x 12.2" (88 x 482 x 312mm) excluding connectors.


Options [++] = Transformers available.
